FMC-28U

Manufacturer part number:FMC-28U

Manufacturer:Sanken

Description:FMC-28U datasheet pdf and Diodes - Rectifiers - Single product details from Sanken stock available on our website

Case Package:SOT-23

Datasheet:FMC-28U Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-220-3 Full Pack
Diode Element Material	SILICON
Packaging	Bulk
Published	2012
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
HTS Code	8541.10.00.80
Capacitance	-220F
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	unknown
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	3
JESD-30 Code	R-XSFM-T2
Qualification Status	Not Qualified
Operating Temperature (Max)	150°C
Number of Elements	1
Configuration	SINGLE
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	100μA @ 800V
Voltage - Forward (Vf) (Max) @ If	3V @ 3A
Case Connection	ISOLATED
Operating Temperature - Junction	-40°C~150°C
Output Current-Max	3A
Application	ULTRA FAST RECOVERY
Max Reverse Voltage (DC)	800V
Average Rectified Current	6A
Number of Phases	1
Reverse Recovery Time	70 ns
JEDEC-95 Code	TO-220AC
Non-rep Pk Forward Current-Max	50A
RoHS Status	RoHS Compliant

FMC-28U Product Details

FMC-28U Overview

As a result, this device has a rectified current of 6A volts on average.Depending on the capacitance, the device may deliver a value of -220F.Output current maximum is 3A.
