Name: TSM-116-02-T-SH
Brand: Samtec Inc.
SKU: TSM-116-02-T-SH
Price: 2.62000 USD
Availability: InStock

new-10%

TSM-116-02-T-SH

Manufacturer part number:TSM-116-02-T-SH

Manufacturer:Samtec Inc.

Description:TSM Series 1-Row Header Solder Phosphor Bronze Tube Surface Mount, Right Angle Tin Liquid Crystal Polymer (LCP) 16-Position Board to Board or Cable 0.120 3.05mm Height

Case Package:SOT-23

Datasheet:TSM-116-02-T-SH Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~105°C
Packaging	Tube
Series	TSM
Published	2012
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	16
Number of Rows	1
Gender	Male
Additional Feature	E.L.P.
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Contact Finish - Mating	Tin
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	16
Terminal Pitch	2.54mm
Insulation Height	0.120 3.05mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Shrouding	Unshrouded
Number Of PCB Rows	1
Contact Length - Mating	0.320 8.13mm
PCB Contact Pattern	RECTANGULAR
Body Depth	0.29 inch
Rated Current (Signal)	3A
Insulation Resistance	5000000000Ohm
Plating Thickness	200μin
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TSM-116-02-T-SH Product Details

TSM-116-02-T-SH Overview

It comes in Header packaging.The device's mounting type is Surface Mount, Right Angle.In order to package the product, a Tube case is used.It belongs to the TSM Series of products.In addition, there are other features such as E.L.P., to mention only a few.The part is mounted by Surface Mount.The device runs in -55°C~105°C Operating Temperature.
