Name: SEAF-30-01-S-04-2-RA-GP-TR
Brand: Samtec Inc.
SKU: SEAF-30-01-S-04-2-RA-GP-TR
Price: 16.84000 USD
Availability: InStock

new

SEAF-30-01-S-04-2-RA-GP-TR

Manufacturer part number:SEAF-30-01-S-04-2-RA-GP-TR

Manufacturer:Samtec Inc.

Description:High Density Array, FemaleTape & Reel (TR)4 Rows0.050 1.27mmSurface Mount, Right Angle120 PositionsSEARAY™ SEAFGoldSolderCOPPER ALLOY

Case Package:SOT-23

Datasheet:SEAF-30-01-S-04-2-RA-GP-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	COPPER ALLOY
Mounting Type	Surface Mount, Right Angle
Insulation Material	LIQUID CRYSTAL POLYMER (LCP)
Mounting Option 1	LOCKING
Packaging	Tape & Reel (TR)
Published	2015
Series	SEARAY™ SEAF
JESD-609 Code	e3
Feature	Board Guide, Mating Flange
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	High Density Array, Female
Number of Positions	120
Number of Rows	4
Gender	Female
Additional Feature	ROHS COMPLIANT,WITH GUIDE POST
Subcategory	Headers and Edge Type Connectors
Pitch	0.050 1.27mm
Total Number of Contacts	120
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	4
PCB Contact Pattern	RECTANGULAR
Operating Temperature (Max)	125°C
Body Breadth	0.312 inch
Operating Temperature (Min)	-55°C
Body Depth	0.592 inch
Rated Current (Signal)	2.1A
Contact Resistance	17.1mOhm
Body/Shell Style	PLUG
Polarization Key	POLARIZED HOUSING
Durability	100 Cycles
Contact Pattern	RECTANGULAR
Insulator Color	BLACK
Contact Finish Thickness	30.0μin 0.76μm
Plating Thickness	30μin
Height Above Board	0.311 7.90mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

SEAF-30-01-S-04-2-RA-GP-TR Product Details

SEAF-30-01-S-04-2-RA-GP-TR Overview

Packaging for this item is High Density Array, Female.It is necessary to use a Tape & Reel (TR) case for packaging the product.There is a mounting type of Surface Mount, Right Angle for this device.This product is part of the SEARAY™ SEAF Series.In operation, it is possible to ensure that Board Guide, Mating Flange is maintained.Moreover, there are a number of other features, including ROHS COMPLIANT,WITH GUIDE POST, to name just a few.
