TRR01MZPF4701

new-10%

Manufacturer part number:TRR01MZPF4701

Manufacturer:ROHM Semiconductor

Description:FIXED RESISTOR SURFACE MOUNT, TRR Series, Thick Film, 4.7kOhm, 0.063W 1/16W, ±1%, -55°C~155°C

Case Package:SOT-23

Datasheet:TRR01MZPF4701 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Package / Case	0402 (1005 Metric)
Surface Mount	YES
Terminal Shape	WRAPAROUND
Mounting Feature	SURFACE MOUNT
Operating Temperature	-55°C~155°C
Packaging	Tape & Reel (TR)
Series	TRR
Published	2012
Size / Dimension	0.039Lx0.020W 1.00mmx0.50mm
Tolerance	±1%
JESD-609 Code	e3
Feature	Anti-Sulfur
Pbfree Code	yes
Part Status	Not For New Designs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Temperature Coefficient	±100ppm/°C
Resistance	4.7kOhm
Terminal Finish	Tin (Sn) - with Nickel (Ni) barrier
Composition	Thick Film
Power (Watts)	0.063W 1/16W
Subcategory	FIXED RESISTOR
Power Rating	63mW
Packing Method	TR, PAPER, 7 INCH
Max Power Dissipation	63mW
Construction	Chip
Resistor Type	FIXED RESISTOR
Reference Standard	TS 16949
Case Code (Metric)	1005
Rated Power Dissipation (P)	0.063W
Case Code (Imperial)	0402
Working Voltage	50V
Height	406.4μm
Height Seated (Max)	0.016 0.40mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
