SN54150J Overview
It is included in the 24-CDIP (0.300, 7.62mm) in order to save board space.As a result, it is packaged in the way of Tube.In terms of mounting, digital switch ic uses the Through Hole method .Data Selector/Multiplexer is the analog IC that the multiplexers uses.As long as the operating temperature is -55°C~125°C, turn signal switch will not be influenced by external factors.When operated with a 4.5V~5.5V supply voltage, digital controlled switch provides digital controlled switch's superior flexibility for designers.
SN54150J Features
Supplied in the 24-CDIP (0.300, 7.62mm) package
SN54150J Applications
There are a lot of Rochester Electronics, LLC SN54150J Signal Switches / Multiplexers / Decoders applications.
- Enabling block of memory depending on address in memory chips
- Implementing boolean functions with multiple variables
- Seven segment displays
- Data transfer
- GLAN
- Video transmission
- HD surveillance system
- Image transmission
- Code conversion
- Logic circuits
