Name: RP131K421B-TR
Brand: RICOH Electronic Devices Co., LTD.
SKU: RP131K421B-TR
Price: 0.38000 USD
Availability: InStock

new-10%

RP131K421B-TR

Manufacturer part number:RP131K421B-TR

Manufacturer:RICOH Electronic Devices Co., LTD.

Description:0.5mm PMIC 6

Case Package:SOT-23

Datasheet:RP131K421B-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Surface Mount	YES
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	6
ECCN Code	EAR99
Terminal Finish	Gold (Au)
HTS Code	8542.39.00.01
Terminal Position	DUAL
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	6
JESD-30 Code	R-PDSO-N6
Qualification Status	Not Qualified
Output Voltage 1	4.2V
Input Voltage (Min)	1.6V
Input Voltage (Max)	6.5V
Output Voltage1-Max	4.2756V
Output Voltage1-Min	4.0908V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Dropout Voltage1-Max	0.65V
Length	2mm
Height Seated (Max)	0.6mm
Width	1.8mm
RoHS Status	RoHS Compliant

RP131K421B-TR Product Details

RP131K421B-TR Overview

In a Tape & Reel (TR) case, the IC voltage regulator is delivered. In total, there are 6 terminations on the gadget. There are 6 pins in total on this board. In this case, the regulator type is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR, which corresponds to this voltage regulator IC.
