TOP256MN Overview
There is a ac to dc converter embedded in package 10-SDIP (0.300, 7.62mm), 9 Leads .The AC/DC power converter is available in Tube .In this case, the AC/DC converter is mounted in the way of Through Hole .The ac dc converter should be operated at a temperature of -40°C~150°C TJ °C to deliver its optimal performance.In this AC DC converter, an analog integrated circuit (IC) of type ANALOG CIRCUIT is employed.66kHz is the switching frequency.As a result, it has had 9 terminations.There are 9 pins on this ac/dc converter.There are no problem mounting the ac dc converters by Through Hole .This AC to DC converter belongs to the TOPSwitch?-HX family of manufacturers.The following ac to dc conversions are contained in Switching Regulator or Controllers .Current output is set to 4.08A .As a result, its output voltage is 700V .A coverter produces 34W watts of output power.It is capable of working with a minimum supply voltage of -300mV volts.
TOP256MN Features
Packaged with 10-SDIP (0.300, 7.62mm), 9 Leads
Switching Frequency at 66kHz
With 9 pins
Output Current at 4.08A
TOP256MN Applications
There are a lot of Power Integrations TOP256MN AC DC Converters applications.
- Off--line Battery Charger
- Humidifier
- Battery Chargers
- WiFi Wireless
- Adapter/Charger for Cordless Phones
- Replaces linear transformers
- RCC SMPS
- IoT Applications
- Battery chargers for cordless
- Power Adaptors
