TOP242P Overview
In the 8-DIP (0.300, 7.62mm), 7 Leads package, the ac to dc converter is embedded.In Bulk case, the ac dc converter is available.The AC/DC converter is mounted in the way of Through Hole .Ideally, the ac dc converter should be operated at a temperature of -40°C~150°C TJ degrees Celsius.In this AC DC converter, the analog IC type is SWITCHING REGULATOR .The switching frequency reaches 66kHz~132kHz .As a result, it has had 7 terminations.On the ac/dc converter, there are 8 pins.There are 8 pins in total.Currently, it is acdc converter of the manufacturer family of TOPSwitch?-GX .AC to DC converter is included in Switching Regulator or Controllers .Ac to dc inverters can be supplied with a maximum current of 0.72A .
TOP242P Features
Packaged with 8-DIP (0.300, 7.62mm), 7 Leads
Switching Frequency at 66kHz~132kHz
With 8 pins
TOP242P Applications
There are a lot of Power Integrations TOP242P AC DC Converters applications.
- 3.3V power supplies
- Off--line Battery Charger
- ATX/BTX Auxiliary Power
- Auxiliary Power Supplies
- Adapter/Charger for Cordless Phones
- White goods
- Power adapters for monitors
- Home appliances
- Universal input AC/DC adapters (15W - 45W)
- Standby power supplies for VCR
