INN2904K Overview
An embedded ac to dc converter is included in 16-SOIC (0.154, 3.90mm Width), 15 Leads package.It is available in Tube AC/DC power converter.There is a mounting point for this AC/DC converter in the way of Surface Mount .The ac dc converter should be operated at a temperature of -40°C~105°C TA °C to deliver its optimal performance.In this AC DC converter, an analog integrated circuit (IC) of type SWITCHING REGULATOR is employed.The switching frequency reaches 100kHz .A total of 15 terminations have been recorded.A ac/dc converter with 16 pins is available.It belongs to the family of InnoSwitch?-EP manufacturers.A maximum current of 1.8A may be supplied to the ac to dc inverter.You are able to read the REACH SVHC standard at: No SVHC .The AC to DC converter can be powered under 484V voltage.It is also possible to discover SUB GRP NEED TO BE ASCT CTRL when using this ACDC converter.A voltage of less than 85V V can be used with the AC to DC inverter.
INN2904K Features
Packaged with 16-SOIC (0.154, 3.90mm Width), 15 Leads
Switching Frequency at 100kHz
With 16 pins
INN2904K Applications
There are a lot of Power Integrations INN2904K AC DC Converters applications.
- Standby Power Supplies
- Replaces linear transformers
- Set Top Boxes (STB)
- Battery chargers for cordless
- ZigBee
- Rice Cooker
- Auxiliary Power Supplies
- AC/DC Adaptors/Chargers for Cell Phones
- USB-PD 2.0
- Battery chargers for media tablets
