1933244

1933244

1933244

Phoenix Contact

1933244 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1933244 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 7 Weeks
Contact MaterialCopper
Mount Through Hole
Mounting Type Through Hole
Insulation Material Nylon
Housing Material Polyamide (PA), Nylon
Weight 1.350004g
PackagingBulk
Published 2010
Series COMBICON PST
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Unshrouded
Number of Positions 8
Color Black
Number of Rows 1
Voltage - Rated 250V
Additional FeaturePA, 94V-0
Voltage - Rated DC 400V
Pitch 0.197 5.00mm
Orientation Straight
Depth 2.8mm
Insulation Height 0.079 2.00mm
Current Rating12A
Termination Style Solder
Voltage 300V
Contact Tail Length 0.138 3.50mm
Max Current Rating 12A
Number of Levels 1
Current 16A
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 26 AWG
Number of Poles 8
Contact Mating Finish Tin
Number of Decks 1
Number of Ways 8
Safety Approval UL
Header Orientation Vertical
Length 40mm
Width 35mm
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
In-Stock:9841 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.62000$0.62
10$0.60700$6.07
50$0.56700$28.35
100$0.52160$52.16
250$0.48200$120.5

1933244 Product Details

1933244 Overview


Mounting type Through Hole is selected for the device.To package the product, we use a Bulk case.This product is part of the COMBICON PST Series.To name a few, there is also PA, 94V-0.By Through Hole, the part is mounted.As with other Header, Male Pins, Unshrouded products, this part has a lot of benefits.

1933244 Features


COMBICON PST series

1933244 Applications


There are a lot of Phoenix Contact 1933244 Terminal Blocks applications.

  • Control panels
  • LED municipal outdoor and street lighting
  • Communication
  • Energy efficient lighting (LED)
  • Military Technology
  • Refrigeration control
  • Embedded systems
  • Data Technology
  • Variable speed/frequency drivers
  • Blowers
