Name: 1912304
Brand: Phoenix Contact
SKU: 1912304
Price: 3.92000 USD
Availability: InStock

new-10%

1912304

Manufacturer part number:1912304

Manufacturer:Phoenix Contact

Description:1912304 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1912304 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polyamide (PA), Nylon
Weight	6.35001g
Packaging	Bulk
Published	2001
Series	COMBICON MVSTBR
Feature	Retention Latches (Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Type	Plug, Female Sockets
Number of Positions	3
Color	Green
Number of Rows	1
Voltage - Rated	250V
Additional Feature	PA, UL 94V0
Pitch	0.197 5.00mm
Depth	9.4mm
Insulation Height	1.024 26.01mm
Current Rating	16A
Termination Style	Screw - Rising Cage Clamp
Voltage	300V
Number of Levels	1
Current	16A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Voltage - IEC	630V
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	3
Safety Approval	UL
Plug Wire Entry	90°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Screw Size	M3
Wire Cross Section	2.5 mm2
Length	10.54mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1912304 Product Details

1912304 Overview

A Screw package is included with it.A Free Hanging (In-Line) mounting type is specified for the device.Packaging for the product is carried out via a Bulk case.It's from the COMBICON MVSTBR Series.Additionally, there are other features, such as PA, UL 94V0.A number of features make the Retention Latches (Wire Side) feature more powerful.There's a Free Hanging mount on the part.Other Plug, Female Sockets products benefit from this part as well.
