Name: 1849024
Brand: Phoenix Contact
SKU: 1849024
Price: 2.84000 USD
Availability: InStock

new-10%

1849024

Manufacturer part number:1849024

Manufacturer:Phoenix Contact

Description:1849024 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1849024 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Gold
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	2.152012g
Packaging	Bulk
Published	2011
Series	COMBICON MSTBA
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	5
Color	Gray
Number of Rows	1
Voltage - Rated	250V
Pitch	0.200 5.08mm
Orientation	Right Angle
Insulation Height	0.339 8.61mm
Current Rating	12A
Termination Style	Solder
Housing Color	Grey
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Current Rating	12A
Number of Levels	1
Current	15A
Number of Decks	1
Voltage - IEC	400V
Number of Ways	5
Header Orientation	90°, Right Angle
Number of Positions Per Level	5
Height	12.1mm
Length	12mm
Width	27.32mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant

1849024 Product Details

1849024 Overview

This product is packaged in a Plug carton.Its mounting type is Through Hole.Packaging the product involves using a Bulk case.The product is a part of the COMBICON MSTBA Series.Mounting of the part is based on Through Hole.Several of the benefits of this part are also shared by other Header, Male Pins, Shrouded (4 Side) products.
