Name: 1830392
Brand: Phoenix Contact
SKU: 1830392
Price: 23.99000 USD
Availability: InStock

new

1830392

Manufacturer part number:1830392

Manufacturer:Phoenix Contact

Description:Bulk 0.150 3.81mm Green 2 Levels Through Hole Header, Male Pins, Shrouded (4 Side) COMBICON MCDV Polyamide (PA), Nylon

Case Package:SOT-23

Datasheet:1830392 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mounting Type	Through Hole
Mount	Through Hole
Housing Material	Polyamide (PA), Nylon
Weight	118.999987g
Published	2011
Series	COMBICON MCDV
Packaging	Bulk
Feature	Mating Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	32
Color	Green
Number of Rows	1
Voltage - Rated	160V
Additional Feature	PBT, 94V-0
HTS Code	8536.69.40.40
Pitch	0.150 3.81mm
Orientation	Straight
Depth	22.7mm
Insulation Height	0.862 21.89mm
Current Rating	8A
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.134 3.40mm
Max Current Rating	8A
Number of Levels	2
Current	8A
Number of Decks	1
Voltage - IEC	320V
Positions Per Level	16
Number of Ways	16
Safety Approval	UL
Header Orientation	Vertical
Fastening Method	CONNECTOR
Width	71.35mm
Length	71.35mm
Height	25.3mm
RoHS Status	RoHS Compliant
Material Flammability Rating	UL94 V-0
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1830392 Product Details

1830392 Overview

The product comes in a package of Plug.Through Hole is the type of mounting for the device.To package the product, a Bulk case is used.The product is a member of the COMBICON MCDV Series.Among other features are PBT, 94V-0, to name only a few.It is more powerful in many ways due to its Mating Flange feature.It is mounted by Through Hole.Compared to other Header, Male Pins, Shrouded (4 Side) products, this part has a lot of benefits to offer.
