Name: 1827428
Brand: Phoenix Contact
SKU: 1827428
Price: 1.44000 USD
Availability: InStock

new-10%

1827428

Manufacturer part number:1827428

Manufacturer:Phoenix Contact

Description:1827428 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1827428 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	SMC
Housing Material	Polyamide (PA), Nylon
Weight	114.00001g
Packaging	Bulk
Published	2011
Series	COMBICON SMC
Feature	Mating Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Color	Green
Number of Rows	1
Voltage - Rated	160V
HTS Code	8536.69.40.40
Pitch	0.150 3.81mm
Orientation	45 deg
Depth	13.1mm
Insulation Height	0.433 11.00mm
Current Rating	8A
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.134 3.40mm
Max Current Rating	8A
Number of Levels	1
Current	8A
Number of Decks	1
Voltage - IEC	320V
Number of Ways	2
Safety Approval	UL; CSA
Header Orientation	45°
Number of Positions Per Level	2
Height	14.4mm
Length	20.01mm
Width	18.01mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1827428 Product Details

1827428 Overview

The packaging contains Plug.Through Hole is the mount type.Packaging for the product is carried out via a Bulk case.There is a product in the COMBICON SMC Series.SMC refers to a package enclosing a device.This feature renders it more powerful in a number of ways because of its Mating Flange feature.It is mounted by Through Hole.Several of the benefits of this part are also shared by other Header, Male Pins, Shrouded (4 Side) products.
