PN10-8R-D datasheet pdf and Terminals - Ring Connectors product details from Panduit Corp stock available on our website
SOT-23
PN10-8R-D Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
4 Weeks
Contact Material
Copper
Contact Plating
Tin
Mount
Free Hanging
Mounting Type
Free Hanging (In-Line)
Weight
1.174804kg
Material - Insulation
Polyamide (PA), Nylon
Packaging
Bulk
Series
Pan-Term®
Published
2006
Pbfree Code
yes
Part Status
Active
Moisture Sensitivity Level (MSL)
Not Applicable
Termination
Crimp
Color
Yellow
Gender
Female
Orientation
Straight
Depth
9.4mm
Wire Gauge
10-12 AWG
Wire Gauge (Max)
10 AWG
Wire Gauge (Min)
12 AWG
Terminal and Terminal Block Type
RING TERMINAL
Insulation Diameter
0.225 (5.72mm)
Insulation
Insulated
Terminal Type
Circular
Stud/Tab Size
8 Stud
Length
26.9mm
Width
9.398mm
Thickness
0.040 1.02mm
Length - Overall
1.060 26.92mm
Width - Outer Edges
0.370 9.40mm
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
In-Stock:12194 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.59000
$0.59
10
$0.57800
$5.78
25
$0.56440
$14.11
50
$0.55040
$27.52
100
$0.52290
$52.29
500
$0.50918
$254.59
PN10-8R-D Product Details
Panduit Terminals - Ring Connectors PN10-8R-D are designed for use in a variety of electrical applications. These terminals are made from high-quality materials and feature a crimp design for easy installation. They are suitable for use with 10-12 AWG wire and feature a #8 ring connector.
Features: - Made from high-quality materials - Crimp design for easy installation - Suitable for use with 10-12 AWG wire - #8 ring connector
Applications: Panduit Terminals - Ring Connectors PN10-8R-D are suitable for a variety of electrical applications, including automotive, industrial, and commercial wiring. They can be used to connect wires to switches, relays, circuit breakers, and other electrical components.
