MA3G655

Name: MA3G655
Brand: Panasonic Electronic Components
SKU: MA3G655
Availability: InStock

new-10%

MA3G655

Manufacturer part number:MA3G655

Manufacturer:Panasonic Electronic Components

Description:MA3G655 datasheet pdf and Diodes - Rectifiers - Arrays product details from Panasonic Electronic Components stock available on our website

Case Package:SOT-23

Datasheet:MA3G655 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TOP-3F
Surface Mount	NO
Diode Element Material	SILICON
Packaging	Bulk
Published	2004
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
HTS Code	8541.10.00.80
Subcategory	Rectifier Diodes
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	10
JESD-30 Code	R-PSFM-T3
Qualification Status	Not Qualified
Operating Temperature (Max)	150°C
Number of Elements	2
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Standard
Current - Reverse Leakage @ Vr	20μA @ 300V
Voltage - Forward (Vf) (Max) @ If	1V @ 10A
Case Connection	ISOLATED
Operating Temperature - Junction	-40°C~150°C
Output Current-Max	20A
Voltage - DC Reverse (Vr) (Max)	300V
Current - Average Rectified (Io)	20A
Number of Phases	1
Reverse Recovery Time	50ns
Rep Pk Reverse Voltage-Max	300V
Non-rep Pk Forward Current-Max	150A
Diode Configuration	1 Pair Common Cathode
RoHS Status	RoHS Compliant
