Name: LNJ115W85RA1
Brand: Panasonic Electronic Components
SKU: LNJ115W85RA1
Availability: InStock

new-10%

LNJ115W85RA1

Manufacturer part number:LNJ115W85RA1

Manufacturer:Panasonic Electronic Components

Description:FILTER UNIT, 80MM - More Details

Case Package:SOT-23

Datasheet:LNJ115W85RA1 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	0605 (1613 Metric)
Number of Pins	4
Shape	RECTANGULAR
Packaging	Tape & Reel (TR)
Published	2008
Size / Dimension	1.60mm Lx1.25mm W
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	4
Color	Blue, Red
Packing Method	BULK
Number of Functions	1
Terminal Pitch	1.3mm
Base Part Number	LNJ115W
Case Code (Metric)	1613
Case Code (Imperial)	0605
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-30°C
Configuration	Common Cathode
Voltage - Forward (Vf) (Typ)	2.9V Blue 1.92V Red
Optoelectronic Device Type	DUAL COLOR LED
Current - Test	5mA Blue 10mA Red
Lens Style	Rectangle with Flat Top
Lens Size	1.10mmx1.25mm
Luminous Intensity	24 mcd
Millicandela Rating	12mcd Blue, 24mcd Red
Wavelength - Peak	465nm Blue 645nm Red
Wavelength - Dominant	470nm Blue 630nm Red
Number of LEDs	2
Height	550μm
Radiation Hardening	No
RoHS Status	RoHS Compliant

About LNJ115W85RA1

The LNJ115W85RA1 from Panasonic Electronic Components is a high-performance microcontroller designed for a wide range of embedded applications. This component features FILTER UNIT, 80MM - More Details.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the LNJ115W85RA1, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
