Res Thick Film 0402 59K Ohm 1% 1/10W 200ppm/C Molded SMD SMD Punched Carrier T/R
SOT-23
ERJ-U02F5902X Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
12 Weeks
Mount
Surface Mount
Weight
793.786648μg
Tolerance
1%
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
SMD/SMT
Temperature Coefficient
200 ppm/°C
Resistance
59kOhm
Max Operating Temperature
155°C
Min Operating Temperature
-55°C
Composition
Thick Film
Voltage - Rated
50V
Power Rating
100mW
Current Rating
1A
Case Code (Metric)
1005
Case Code (Imperial)
0402
Height
350μm
Length
1mm
Width
500μm
RoHS Status
ROHS3 Compliant
In-Stock:636150 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.113093
$0.113093
10
$0.106691
$1.06691
100
$0.100653
$10.0653
500
$0.094955
$47.4775
1000
$0.089580
$89.58
ERJ-U02F5902X Product Details
The Panasonic Chip Resistor - Surface Mount ERJ-U02F5902X is a high-performance, reliable resistor designed for use in a variety of applications. This resistor features a 0402 size, 59K Ohm resistance, 1% tolerance, 1/10W power rating, and 200ppm/C temperature coefficient. It is constructed with a thick film technology and is molded in a SMD package with a punched carrier T/R. This resistor is ideal for use in high-density circuit boards and other applications where space is limited. It is designed to provide superior performance and reliability in a wide range of temperatures and environments. The Panasonic Chip Resistor - Surface Mount ERJ-U02F5902X is an excellent choice for any application requiring a reliable, high-performance resistor.
