Res Thick Film 0402 11.5K Ohm 1% 1/10W 200ppm/C Molded SMD SMD Punched Carrier T/R
SOT-23
ERJ-U02F1152X Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
12 Weeks
Mount
Surface Mount
Weight
793.786648μg
Tolerance
1%
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
SMD/SMT
Temperature Coefficient
200 ppm/°C
Resistance
11.5kOhm
Max Operating Temperature
155°C
Min Operating Temperature
-55°C
Composition
Thick Film
Voltage - Rated
50V
Power Rating
100mW
Voltage - Rated DC
50V
Current Rating
1A
Case Code (Metric)
1005
Case Code (Imperial)
0402
Height
350μm
Length
1mm
Width
500μm
RoHS Status
ROHS3 Compliant
In-Stock:649636 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$0.106149
$0.106149
10
$0.100140
$1.0014
100
$0.094472
$9.4472
500
$0.089124
$44.562
1000
$0.084080
$84.08
ERJ-U02F1152X Product Details
The Panasonic Chip Resistor - Surface Mount ERJ-U02F1152X is a thick film resistor with a resistance of 11.5K Ohms and a tolerance of 1%. It has a power rating of 1/10W and a temperature coefficient of 200ppm/C. It is a molded SMD resistor with a punched carrier tape and reel packaging.
Features of the Panasonic Chip Resistor - Surface Mount ERJ-U02F1152X include a small size of 0402, a high resistance of 11.5K Ohms, a low tolerance of 1%, a low power rating of 1/10W, and a low temperature coefficient of 200ppm/C.
Applications of the Panasonic Chip Resistor - Surface Mount ERJ-U02F1152X include use in consumer electronics, automotive electronics, and industrial electronics. It is suitable for use in applications that require a small size, high resistance, low tolerance, low power rating, and low temperature coefficient.
