ECW-U2393JC9

  • ECW-U2393JC9 - ECW-U(C) 0.039μF Film Capacitor ±5% 2416 (6041 Metric) Solder Pads 250V-DC 250V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount
  • ECW-U2393JC9 - ECW-U(C) 0.039μF Film Capacitor ±5% 2416 (6041 Metric) Solder Pads 250V-DC 250V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount

ECW-U2393JC9

ECW-U2393JC9

Panasonic Electronic Components

ECW-U(C) 0.039μF Film Capacitor ±5% 2416 (6041 Metric) Solder Pads 250V-DC 250V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount

SOT-23

ECW-U2393JC9 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2416 (6041 Metric)
Terminal Shape WRAPAROUND
Dielectric MaterialPolyester, Polyethylene Naphthalate (PEN), Metallized - Stacked
Operating Temperature-55°C~125°C
PackagingTape & Reel (TR)
Published 2011
Series ECW-U(C)
Size / Dimension 0.236Lx0.161W 6.00mmx4.10mm
Tolerance ±5%
JESD-609 Code e1
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 2
Termination Solder Pads
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications General Purpose
HTS Code8532.25.00.45
Capacitance 0.039μF
Voltage - Rated DC 250V
Packing Method TR
Depth 4.1mm
Voltage - Rated AC 250V
Case Code (Metric) 6041
Case Code (Imperial) 2416
Capacitor Type FILM CAPACITOR
Height 2mm
Height Seated (Max) 0.087 2.20mm
Length 6mm
REACH SVHC No SVHC
RoHS StatusRoHS Compliant
Lead Free Contains Lead
In-Stock:4274 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$1.690711$1.690711
10$1.595011$15.95011
100$1.504727$150.4727
500$1.419554$709.777
1000$1.339201$1339.201

ECW-U2393JC9 Product Details

ECW-U2393JC9 Overview


The device is capable of operating at the temperature of -55°C~125°C.

ECW-U2393JC9 Features



ECW-U2393JC9 Applications


There are a lot of Panasonic Electronic Components ECW-U2393JC9 applications of film capacitors.

  • Mobile communications
  • Snubbering
  • Global positioning systems
  • RFI for automotive
  • Audio/video equipment
  • Blocking
  • Bypassing
  • Switch-mode power supplies
  • Filtering
  • Switch mode power supplies
