ECW-U1682JX5

  • ECW-U1682JX5 - ECW-U(X) 6800pF Film Capacitor ±5% 1210 (3225 Metric) Solder Pads 100V-DC 100V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount
  • ECW-U1682JX5 - ECW-U(X) 6800pF Film Capacitor ±5% 1210 (3225 Metric) Solder Pads 100V-DC 100V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount

ECW-U1682JX5

ECW-U1682JX5

Panasonic Electronic Components

ECW-U(X) 6800pF Film Capacitor ±5% 1210 (3225 Metric) Solder Pads 100V-DC 100V-AC Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked Surface Mount

SOT-23

ECW-U1682JX5 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 8 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Terminal Shape WRAPAROUND
Dielectric MaterialPolyester, Polyethylene Naphthalate (PEN), Metallized - Stacked
Operating Temperature-55°C~105°C
PackagingTape & Reel (TR)
Published 2010
Series ECW-U(X)
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Tolerance ±5%
JESD-609 Code e1
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 2
Termination Solder Pads
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications General Purpose
HTS Code8532.25.00.45
Capacitance 6800pF
Voltage - Rated DC 100V
Packing Method TR
Depth 2.5mm
Voltage - Rated AC 100V
Case Code (Metric) 3225
Case Code (Imperial) 1210
Capacitor Type FILM CAPACITOR
Height 1.5mm
Height Seated (Max) 0.067 1.70mm
Length 3.2mm
REACH SVHC No SVHC
RoHS StatusROHS3 Compliant
Lead Free Contains Lead
In-Stock:8940 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.800863$0.800863
10$0.755531$7.55531
100$0.712765$71.2765
500$0.672421$336.2105
1000$0.634359$634.359

ECW-U1682JX5 Product Details

ECW-U1682JX5 Overview


Temperatures of -55°C~105°C are suitable for operating the device.

ECW-U1682JX5 Features




ECW-U1682JX5 Applications


There are a lot of Panasonic Electronic Components
ECW-U1682JX5 applications of film capacitors.


  • RF Modules
  • Mobile communications
  • Satellite TV
  • Global positioning systems
  • Filters
  • VCO's
  • Matching networks
  • Snubbering
  • Filtering
  • IGBT
