ECW-FG1B225J

  • ECW-FG1B225J - ECWFG 2.2μF Film Capacitor ±5% Radial PC Pins 1100V 1.1kV-DC Polypropylene (PP), Metallized
  • ECW-FG1B225J - ECWFG 2.2μF Film Capacitor ±5% Radial PC Pins 1100V 1.1kV-DC Polypropylene (PP), Metallized

ECW-FG1B225J

ECW-FG1B225J

Panasonic Electronic Components

ECWFG 2.2μF Film Capacitor ±5% Radial PC Pins 1100V 1.1kV-DC Polypropylene (PP), Metallized

SOT-23

ECW-FG1B225J Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 13 Weeks
Mounting Type Through Hole
Package / Case Radial
Dielectric MaterialPolypropylene (PP), Metallized
Operating Temperature-40°C~110°C
PackagingBulk
Series ECWFG
Size / Dimension 1.240Lx0.531W 31.50mmx13.50mm
Tolerance ±5%
Feature High Temperature
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pins
Applications Automotive; High Frequency, Switching
Capacitance 2.2μF
Voltage - Rated DC 1100V 1.1kV
Lead Spacing1.083 27.50mm
Height Seated (Max) 1.142 29.00mm
RoHS StatusROHS3 Compliant
Ratings AEC-Q200
In-Stock:3211 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$2.61000$2.61
500$2.5839$1291.95
1000$2.5578$2557.8
1500$2.5317$3797.55
2000$2.5056$5011.2
2500$2.4795$6198.75

ECW-FG1B225J Product Details

ECW-FG1B225J Overview


Lead spacing is 1.083 27.50mm for this electrical device.In a temperature range of -40°C~110°C, the device can be operated.

ECW-FG1B225J Features



ECW-FG1B225J Applications


There are a lot of Panasonic Electronic Components ECW-FG1B225J applications of film capacitors.

  • Lighting
  • Bypassing
  • Satellite TV
  • Coupling, decoupling
  • VCO's
  • Switch mode power supplies
  • Switch-mode power supplies
  • Electronic ballasts
  • Filters
  • RF Modules
