EEH-ZF1H101V Overview
Systems need 900 mA @ 100 kHz ripple current at high frequency to be powered.In this electrical device, the ESR (Equivalent Series Resistance) is 28mOhm.To enable 135 mA @ 100 Hz to fully perform its function, a ripple current @ Low Frequency must be provided.If this occurs, the load can only be supplied with 100uF capacitance value.An operating temperature of -55°C ~ 150°C is recommended for stable operation.
EEH-ZF1H101V Features
900 mA @ 100 kHz ripple current on a high frequency
a 28mOhm in ESR (Equivalent Series Resistance) in this electrical device
with 100uF capacitance value in this case
an operating temperature of -55°C ~ 150°C
EEH-ZF1H101V Applications
There are a lot of Panasonic
EEH-ZF1H101V applications of aluminum polymer capacitors.
- LED driver power supplies
- Phone chargers
- Motherboards
- Servers and adapters (laptop power supplies)
- Medical equipment
- Switching Power Supply and DC/DC Converter.
- Buck up Power Supplies of CPU(VRM etc.)
- Miniature high Power Supply.
