Name: EEH-AZS1H151B
Brand: Panasonic
SKU: EEH-AZS1H151B
Availability: InStock

new-10%

EEH-AZS1H151B

Manufacturer part number:EEH-AZS1H151B

Manufacturer:Panasonic

Description:150µF 20% Radial, Can Tape and Box 14mOhm ZS-A Through Hole Polymer Hybrid Automotive

Case Package:SOT-23

Datasheet:EEH-AZS1H151B Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	Radial, Can
Number of Terminals	2
Surface Mount Land Size	-
Product Weight (g)	1.635
ECCN (US)	EAR99
Capacitance Value	150uF
ESR (Ohm)	0.017
Equivalent Series Resistance Type	Low
IR (mA)	3200
IL (uA)	75@2Min
Lifetime (h)	4000
Mounting	Through Hole
Terminal Pitch (mm)	5
Wire Form	Long Lead
Size (mm)	10 X 11.7
Minimum Operating Temperature (°C)	-55
Maximum Operating Temperature (°C)	125
Lead Diameter (mm)	0.8
Product Diameter (mm)	10
Qualification	AEC-Q200
Capacitance Tolerance	± 20%
Package Type	Can
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 55 C
Manufacturer	Panasonic
Brand	Panasonic
RoHS	Details
Package	Cut Tape (CT);Tape & Box (TB);
Base Product Number	EEH-AZS
Mfr	Panasonic Electronic Components
Product Status	Active
Height - Seated (Max)	0.500 (12.70mm)
Lifetime @ Temp.	4000 Hrs @ 125°C
Packaging	Tape and Box
Series	ZS-A
Operating Temperature	-55°C ~ 125°C
Size / Dimension	0.394 Dia (10.00mm)
Tolerance	20%
Type	Polymer Hybrid
Applications	Automotive
Voltage - Rated	50 V
Capacitance	150µF
Subcategory	Capacitors
Construction	Aluminum Cylindrical Can
Termination Style	Radial
ESR (Equivalent Series Resistance)	14mOhm
Polarity	Polar
Lead Spacing	0.197 (5.00mm)
Voltage	50VDC
Ripple Current	3.2 A
Ripple Current @ Low Frequency	480 mA @ 100 Hz
Ripple Current @ High Frequency	3.2 A @ 100 kHz
Product Type	Electrolytic Capacitors
ESR	0.017ohm
Product	Aluminum Hybrid Polymer Capacitors
Product Category	Aluminum Organic Polymer Capacitors
Product Length	-
Product Width	-
Width	-
Height	-
Length	11.7 mm
Diameter	10 mm
Product Height	11.7mm
Product Height (mm)	11.7
RoHS Status	RoHS Compliant
Ratings	AEC-Q200

EEH-AZS1H151B Product Details

EEH-AZS1H151B Overview

System power is determined by 3.2 A @ 100 kHz ripple current on a high frequency.Electrical device with 14mOhm ESR (Equivalent Series Resistance).To fully perform the function of 480 mA @ 100 Hz, a ripple current at low frequency must be provided.As a result, the load can only be supplied with 150uF capacitance.It is recommended to operate at -55°C ~ 125°C for stable operation.

EEH-AZS1H151B Features

3.2 A @ 100 kHz ripple current on a high frequency
a 14mOhm in ESR (Equivalent Series Resistance) in this electrical device
with 150uF capacitance value in this case
an operating temperature of -55°C ~ 125°C
