NCV8509PDW25 Overview
Deliveries are in Tube cases. The package is in a 16-SOIC (0.295, 7.50mm Width) Exposed Pad case. Basically, the voltage regulator chip is made up of 16 terminations. In this case, Fixed represents the output type of the Voltage Regulated IC. This part implements 2 regulator ICs, which can be found in the following table. Regulator IC varies the range of Surface Mount operating temperatures. The Voltage Regulated IC operates at a temperature of -40°C~125°C degrees, which is its operating temperature. It is configured for output function Positive on this regulator. There is an output current of 115mA 100mA on this regulator. The total number of pins in the regulator is 16. This IC regulator has a total of 2 outputs, which ensures a rapid, adequate performance when in use. There is a voltage dropout of 10 volts for this IC regulator. Several pins on the chip are 16-shaped. As an FYI, this IC voltage regulator has the basic part number NCV8509. Packing the voltage regulator IC in this way is called RAIL packing. As part of the Automotive, AEC-Q100 Series, this IC voltage regulator belongs to that category.
NCV8509PDW25 Features
400mV dropout voltage
RAIL method of packing
NCV8509PDW25 Applications
There are a lot of ON Semiconductor
NCV8509PDW25 Linear Voltage Regulators applications.
- Electronic notebook
- Camera
- Video equipment
- CPU power supply
- Switching regulator
- Multiple-power supply system
- Digital audio player
- Digital TV
- Smartcard
- Industrial equipment
