NC7ST02P5 Overview
The part can be shipped overseas conveniently because it is packaged in 5-TSSOP, SC-70-5, SOT-353. In order to provide high reliability, an advanced packaging method Tape & Reel (TR) is used. As a result, it works on the principle of NOR Gate. The part must have a voltage of 4.5V~5.5V in order to function properly. Operating temperature around -40°C~85°C extended. Surface Mount is the mounting position of the part. In the low and high states of output current, the current is 2mA 2mA. This is part of the 7ST series. In total, there are 5 terminations. 1 functions in the part enhance the user experience significantly. The chip is part of the HST/T family. Use 7ST02 to search for device variants. Many applications use this logic device with Surface Mount mounting. The functions of 70 pins can be found in the datasheets. There are 2 inputs on this part. When the part is quiescent, 1μA current flows through it. It has a load capacitance of 50pF. There is an industry TAPE AND REEL method included. The datasheet specifies that the part requires 5V volts of power. It is specified that the operating supply voltage for the chip will be 5V volts. A logical operation through a gate of 1.
NC7ST02P5 Features
NOR Gate Logic Type
Operating Temperature: -40°C~85°C
HST/T Family
Quiescent Current: 1μA
1 Gates
