NC7S32P5X Overview
The part comes in 5-TSSOP, SC-70-5, SOT-353 packaging, which makes it convenient to ship overseas. To ensure high reliability, a new packaging method Tape & Reel (TR) is used. A OR Gate logic principle is used to make it work. It is necessary to ensure the full functionality of the part by providing a voltage of 2V~6V. Around -40°C~85°C is the extended operating temperature. There is a hole in Surface Mount for mounting the part. In both high and low states, output current is 2.6mA 2.6mA. This item is from the 7S series. In total, 5 terminations have occurred. This part is equipped with 1 functions that will greatly enhance the user's experience. It is part of the HC/UH family of chips. 7S32 can help you find device variants. Many applications require the use of this logic device with its Surface Mount mounting. The datasheets for the 5 pins explain the functions. Inputs for this part are 2. Parts in quiescent state carry 1μA current. In order for the device to work, a minimum voltage of 2V is required. Upon reaching 6V, the highest supply voltage (Vsup) is reached. Contains the industry TAPE AND REEL method. A device rated at 2.6mA has 2.6mA output current. The logic of 1 gates.
NC7S32P5X Features
OR Gate Logic Type
Operating Temperature: -40°C~85°C
HC/UH Family
Quiescent Current: 1μA
Output Current: 2.6mA
1 Gates
