FS6131-01I-XTD Overview
It is packaged using the Tube method since it is a clock IC. The 16-SOIC (0.154, 3.90mm Width) package embeds this Clock PLL. The frequency generator is capable of withstanding a maximum temperature of 225 during reflowing. 16 terminations can be found in frequency synthesizer. This electronic frequency generator requires a voltage of 5V. Crystal is designed as this clock generator's input. There are 1 circuits implemented in order to achieve full performance from this electronic part. 230MHz is the maximal value for normal operation. Due to the Surface Mount-shape, this electronic component can be conveniently installed on the panel. In terms of supply voltage, RF synthesizer works with 4.5V~5.5V. Test statistics estimate a temperature of -40°C~85°C, which should be set as the ambient temperature. In this case, we are dealing with a frequency synthesizer that can be used with CMOS, PECL logic levels. It has been classified as a PLL Clock Generator electronic part, which means that it is a semiconductor. Microprocessor-specific clock PLL with 16 bits. According to the base part number, its related parts can be founded. There are 16 pins on the frequency generator that are available for use. PLL clock can handle a voltage of 5V as its supply voltage. At a frequency of 28MHz, the system can achieve high efficiency. A supply current of 100mA needs to be provided to fully play RF synthesizer's function.
FS6131-01I-XTD Features
Available in the 16-SOIC (0.154, 3.90mm Width)
Supply voltage of 5V
Operating supply voltage of 5V
FS6131-01I-XTD Applications
There are a lot of ON Semiconductor FS6131-01I-XTD Clock Generators applications.
- FMCW Radar
- Signal analyzer
- Wireless base station for LTE, LTE-advanced
- Automatic test equipment
- Instrument
- 1 Gigabit Ethernet
- Modems
- Antenna automatic tracking
- Sampling clocks for ADC and DAC
- Wide area power system
