FFA15U120DNTU

  • FFA15U120DNTU - FFA15U120DNTU datasheet pdf and Diodes - Rectifiers - Arrays product details from ON Semiconductor stock available on our website
  • FFA15U120DNTU - FFA15U120DNTU datasheet pdf and Diodes - Rectifiers - Arrays product details from ON Semiconductor stock available on our website

FFA15U120DNTU

FFA15U120DNTU

ON Semiconductor

FFA15U120DNTU datasheet pdf and Diodes - Rectifiers - Arrays product details from ON Semiconductor stock available on our website

SOT-23

FFA15U120DNTU Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Mounting Type Through Hole
Package / Case TO-3P-3, SC-65-3
Supplier Device Package TO-3P
PackagingTube
Part StatusObsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 3.5V @ 15A
Operating Temperature - Junction -65°C~150°C
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 15A
Reverse Recovery Time 100ns
Diode Configuration 1 Pair Common Cathode
In-Stock:3263 items

FFA15U120DNTU Product Details

FFA15U120DNTU Overview




FFA15U120DNTU Features



FFA15U120DNTU Applications


There are a lot of ON Semiconductor FFA15U120DNTU applications of rectifier diode array.

  • Rectifier for drives applications
  • Battery chargers
  • Crowbar applications
  • Rectifiers in switch mode power supplies (SMPS)
  • Free wheeling diode in low voltage converters
  • General Rectification
  • Rectifiers for UBS
