FAN7601M Overview
The ac to dc converter is embedded in 8-SOIC (0.154, 3.90mm Width) package.The AC/DC power converter Tube is available for this product.It is mounted in the way of Surface Mount .The ac dc converter should be operated at a temperature of -25°C~125°C TA °C to deliver its optimal performance.An analog IC of type SWITCHING CONTROLLER is employed in this AC DC converter.The switching frequency reaches Up to 300kHz .This AC/DC converter is designed for use within the range of 8V~20V supply voltage (Vcc/Vdd).Total terminations are 8 .There are 8 pins on this ac/dc converter.Suitable mounting is provided by Surface Mount .It is possible to search for similar acdc converters by using the FAN7601 family.AC to DC converter is necessary to run 1 outputs.We have set the output current to 250mA .As a result, its output voltage is 12V .There is a maximum current limAC to DC converter of 4mA for the supply.The AC to DC power supply consumes quiescent current at 3mA .
FAN7601M Features
Packaged with 8-SOIC (0.154, 3.90mm Width)
Switching Frequency at Up to 300kHz
With 8 pins
Output Current at 250mA
FAN7601M Applications
There are a lot of ON Semiconductor FAN7601M AC DC Converters applications.
- Digital cameras
- Low-Voltage I/O System Power
- AC/DC Adaptors/Chargers for E-books
- Shaver Charger
- Smartphones
- SMPS house keeping power supplies
- Automotive Infotainment
- Adaptors for Portable Media Player
- Power adapters for network devices
- Off--line Battery Charger
