ATP106-TL-H Overview
An op amp's input capacitance is defined as the capacitance between both of its input terminals with either input grounded, and 1380pF @ 20V is its maximum input capacitance.The drain current is the maximum continuous current the device can conduct, and this device has 30A continuous drain current (ID).A drainage-to-source breakdown voltage corresponds to the voltage at which a specified value of ID flows, where VGS is 40V, and this device has a drainage-to-source breakdown voltage of 40VV.Input capacitance must be charged before drain current conduction can begin, so the turn-off delay time is 110 ns.Before drain current conduction begins, the device's input capacitance must be charged, so the delay time is 12 ns.An FET transistor's gate-source voltage, VGS, indicates how much voltage is applied across the transistor's gate-source terminal and it can range from 20V to 1.Using drive voltage (4.5V 10V), this device contributes to a reduction in overall power consumption.
ATP106-TL-H Features
a continuous drain current (ID) of 30A
a drain-to-source breakdown voltage of 40V voltage
the turn-off delay time is 110 ns
ATP106-TL-H Applications
There are a lot of ON Semiconductor
ATP106-TL-H applications of single MOSFETs transistors.
- AC-DC Power Supply
- Synchronous Rectification for ATX 1 Server I Telecom PSU
- Motor drives and Uninterruptible Power Supplies
- Micro Solar Inverter
- DC/DC converters
- Power Tools
- Motor Drives and Uninterruptible Power Supples
- Synchronous Rectification
- Battery Protection Circuit
- Telecom 1 Sever Power Supplies
