Name: MC9S08PA8VLC
Brand: NXP USA Inc.
SKU: MC9S08PA8VLC
Availability: InStock

new-10%

MC9S08PA8VLC

Manufacturer part number:MC9S08PA8VLC

Manufacturer:NXP USA Inc.

Description:8KB 8K x 8 FLASH 8-Bit Microcontroller S08 Series MC9S08PA8 3V 32-LQFP

Case Package:SOT-23

Datasheet:MC9S08PA8VLC Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Mounting Type	Surface Mount
Package / Case	32-LQFP
Surface Mount	YES
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	S08
Published	2012
JESD-609 Code	e3
Part Status	Not For New Designs
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	32
ECCN Code	3A991.A.2
Terminal Finish	Tin (Sn)
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.8mm
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	MC9S08PA8
JESD-30 Code	S-PQFP-G32
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5V
Supply Voltage-Min (Vsup)	2.7V
Oscillator Type	Internal
Number of I/O	28
Speed	20MHz
RAM Size	2K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Peripherals	LVD, POR, PWM, WDT
Clock Frequency	20MHz
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	8KB 8K x 8
Connectivity	I2C, LINbus, SPI, UART/USART
Supply Current-Max	14mA
Bit Size	8
Data Converter	A/D 12x12b
Has ADC	YES
DMA Channels	NO
PWM Channels	YES
ROM (words)	8192
EEPROM Size	256 x 8
Length	7mm
Width	7mm
RoHS Status	ROHS3 Compliant

MC9S08PA8VLC Product Details

MC9S08PA8VLC Description
