Name: LPC3220FET296,551
Brand: NXP USA Inc.
SKU: LPC3220FET296,551
Availability: InStock

new-10%

LPC3220FET296,551

Manufacturer part number:LPC3220FET296,551

Manufacturer:NXP USA Inc.

Description:ROMless ARM926EJ-S 16/32-Bit Microcontroller LPC3200 Series LPC32*0 1.35V 296-TFBGA

Case Package:SOT-23

Datasheet:LPC3220FET296,551 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	296-TFBGA
Surface Mount	YES
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	LPC3200
Published	2008
JESD-609 Code	e1
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	296
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code	8542.31.00.01
Subcategory	Microcontrollers
Technology	CMOS
Terminal Position	BOTTOM
Terminal Form	BALL
Peak Reflow Temperature (Cel)	260
Supply Voltage	1.35V
Terminal Pitch	0.8mm
Reach Compliance Code	unknown
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	LPC32*0
Pin Count	296
JESD-30 Code	S-PBGA-B296
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	1.39V
Power Supplies	1.33.3V
Supply Voltage-Min (Vsup)	1.31V
Oscillator Type	Internal
Number of I/O	51
Speed	266MHz
RAM Size	128K x 8
Voltage - Supply (Vcc/Vdd)	0.9V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM926EJ-S
Peripherals	DMA, I2S, Motor Control PWM, PWM, WDT
Clock Frequency	20MHz
Program Memory Type	ROMless
Core Size	16/32-Bit
Connectivity	EBI/EMI, I2C, IrDA, Microwire, SPI, SSI, SSP, UART/USART, USB OTG
Bit Size	32
Data Converter	A/D 3x10b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	NO
ROM (words)	16384
ROM Programmability	FLASH
Source Url Status Check Date	2013-06-14 00:00:00
Length	15mm
Height Seated (Max)	1.2mm
Width	15mm
RoHS Status	ROHS3 Compliant

LPC3220FET296,551 Product Details

LPC3220FET296,551 Overview

This Microcontroller comes in a 296-TFBGA package. This Microcontroller has 51 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 16/32-Bit core. This Microcontroller's program memory type is ROMless. The Microcontroller runs in -40°C~85°C TA Operating Temperature. Microcontroller runs in LPC3200 Series. MCU is powered by ARM926EJ-S Core Processor. The device belongs to MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs Type. The MCU has a number of 296 terminals. Microcontroller comes with 32 bit size. The component always operates in 1.35V supply voltage. MCU chip has YES DMA channels. You can find alternatives through the base part number LPC32*0. The device works in YES PWM channels. It counts 296 pins. It is at 20MHz clock frequency.
