74ABT16841ADL,518 Overview
A package called 56-BSSOP (0.295, 7.50mm Width) contains it. Tape & Reel (TR) is the way in which it is packaged. Tri-State is the output configured for it. This electrical device has a logic type of D-Type Transparent Latch. Based on the way of Surface Mount, this electronic part is mounted. In order for it to operate, it needs a supply voltage of 4.5V~5.5V. A temperature of -40°C~85°C is set as the operating temperature. This FPGA is part of the 74ABT series. The design of this electronic part is based on 10 bits. In this device, there are 56 terminations. The family 74ABT16841 includes it. In order to function, the supply voltage should be set to 5V. There are 56 pins attached to it. In the world of electronics, this electronic device belongs to the family of ABT. In this device, there is a total of 2 ports available for use. Vsup reaches 5.5V as the maximum supply voltage. There should be a voltage supply (Vsup) greater than 4.5V. Its maximum current supply (ICC) reaches 19mA.
74ABT16841ADL,518 Features
56-BSSOP (0.295, 7.50mm Width) package
74ABT series
10 Bits
74ABT16841 family
56 pin count
74ABT16841ADL,518 Applications
There are a lot of NXP USA Inc. 74ABT16841ADL,518 Latches applications.
- Up-Down Johnson
- Shift left register
- OC-48 communication systems
- General-Purpose Register
- Shift right register
- Accumulator Registers
- Automotive Body Electronics
- Sample and hold register
- Meter applications
- Automotive Cluster
