Name: S912XEG384J3CAGR
Brand: NXP Semiconductors / Freescale
SKU: S912XEG384J3CAGR
Availability: InStock

new-10%

S912XEG384J3CAGR

Manufacturer part number:S912XEG384J3CAGR

Manufacturer:NXP Semiconductors / Freescale

Description:Microcontroller 1.8V LQFP

Case Package:SOT-23

Datasheet:S912XEG384J3CAGR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	LQFP
Surface Mount	YES
Packaging	Tape & Reel
JESD-609 Code	e3
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	144
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
HTS Code	8542.31.00.01
Subcategory	Microcontrollers
Technology	CMOS
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	1.8V
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	40
JESD-30 Code	S-PQFP-G144
Supply Voltage-Max (Vsup)	1.98V
Power Supplies	3.3/5V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.72V
Interface	CAN, I2C, SCI, SPI
Memory Size	384kB
Number of I/O	119
RAM Size	24kB
Memory Type	FLASH
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Bit Size	16
Frequency (Max)	50MHz
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
Halogen Free	Halogen Free
Number of Timers/Counters	25
Address Bus Width	23
ROM (words)	393216
CPU Family	CPU12
Number of Programmable I/O	119
RAM (bytes)	24576
Length	20mm
Radiation Hardening	No
RoHS Status	RoHS Compliant

S912XEG384J3CAGR Product Details

S912XEG384J3CAGR Overview

This Microcontroller comes in a LQFP package. This Microcontroller has 119 I/Os. The device belongs to MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs Type. The MCU has a number of 144 terminals. Microcontroller comes with 16 bit size. The component always operates in 1.8V supply voltage. MCU chip has YES DMA channels. The part owns 384kB memory size. The device works in YES PWM channels. It has 25 timers/counters. The device is embedded with CPU12 CPU family. This equipment features FLASH memory. It programs in 119 Programmable I/O.
