Name: 27644602RP2
Brand: NorComp Inc.
SKU: 27644602RP2
Price: 6.97000 USD
Availability: InStock

new-10%

27644602RP2

Manufacturer part number:27644602RP2

Manufacturer:NorComp Inc.

Description:2764 Series 2-Row Header Solder Copper Alloy Bulk Through Hole, Right Angle Gold Polyamide (PA6T), Nylon 6T 46-Position Board to Board or Cable 0.158 4.01mm Height

Case Package:SOT-23

Datasheet:27644602RP2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyamide (PA6T), Nylon 6T
Housing Material	Nylon
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	2764
Published	2008
Part Status	Active
Moisture Sensitivity Level (MSL)	Not Applicable
Termination	Solder
Connector Type	Header
Number of Positions	46
Number of Rows	2
Gender	Male
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Type	Male Pin
Current Rating (Amps)	1A
Insulation Height	0.158 4.01mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.079 2.00mm
Row Spacing - Mating	0.079 (2.00mm)
Contact Length - Post	0.118 3.00mm
Shrouding	Unshrouded
Lead Pitch	2mm
Number of Contacts	23
Contact Length - Mating	0.150 3.81mm
Housing Color	Black
Contact Finish Thickness - Mating	Flash
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

27644602RP2 Product Details

27644602RP2 Overview

Packaging is in the form of Header.This device has a Through Hole, Right Angle mounting type.An orange Bulk case is used to package the product.Specifically, it is one of the products in the 2764 Series.There is a mounting hole at Through Hole.Devices operate at -40°C~105°C operating temperatures.
