Name: 189-015-413R571
Brand: NorComp Inc.
SKU: 189-015-413R571
Price: 11.80000 USD
Availability: InStock

new

189-015-413R571

Manufacturer part number:189-015-413R571

Manufacturer:NorComp Inc.

Description:189-015-413R571 datasheet pdf and D-Sub Connectors product details from NorComp Inc. stock available on our website

Case Package:SOT-23

Datasheet:189-015-413R571 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Contact Material	Brass
Mount	Edge, Through Hole
Mounting Type	Panel Mount, Through Hole, Right Angle
Dielectric Material	Polyamide (PA9T), Nylon 9T
Housing Material	Nylon
Body Material	Steel
Shell Material, Finish	Steel, Nickel Plated
Operating Temperature	-55°C~105°C
Packaging	Tray
Published	2009
Series	189
JESD-609 Code	e4
Feature	Board Lock, Grounding Indents, Shielded
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	Not Applicable
Termination	Solder
Connector Type	Plug, Male Pins; Receptacle, Female Sockets
Number of Positions	15, 15
Color	Black
Number of Rows	2, 2
Gender	Male to Female
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating	5A
Contact Finish	Gold
Number of Contacts	15
Mating Information	MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code	94V-0
Empty Shell	NO
Flange Feature	Mating Side, Female Screwlock (4-40)
Plating	Nickel
Connector Style	D-Sub - Stacked
Contact Form	Stamped
Shell Size, Connector Layout	2 DA A ; 2 DA A
Backset Spacing	0.318 (8.08mm)
Height	29.2mm
Length	39mm
Width	25.4mm
Contact Finish Thickness	Flash
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

189-015-413R571 Product Details

189-015-413R571 Overview

Currently, it is packaged in Plug, Male Pins; Receptacle, Female Sockets.This device's mounting type is Panel Mount, Through Hole, Right Angle.A Tray case is used for packaging.It belongs to the 189 Series of products.Its Board Lock, Grounding Indents, Shielded feature makes it more powerful in a number of ways.Mounted by Edge, Through Hole.In this case, the device runs at -55°C~105°C Operating Temperature.
