74LVC2G02DP-Q100H Overview
The part can be shipped overseas conveniently because it is packaged in 8-TSSOP, 8-MSOP (0.118, 3.00mm Width). In order to provide high reliability, an advanced packaging method Tape & Reel (TR) is used. As a result, it works on the principle of NOR Gate. The part must have a voltage of 1.65V~5.5V in order to function properly. Operating temperature around -40°C~125°C extended. Surface Mount is the mounting position of the part. In the low and high states of output current, the current is 32mA 32mA. This is part of the 74LVC series. In total, there are 8 terminations. 2 functions in the part enhance the user experience significantly. The chip is part of the LVC/LCX/Z family. Use 74LVC2G02 to search for device variants. There are 8 pins injected into the part body. Many applications use this logic device with Surface Mount mounting. The functions of 8 pins can be found in the datasheets. When the part is quiescent, 10μA current flows through it. A total of 2 circuits make up this device. As soon as Vsup reaches 5.5V, the maximal supply voltage (Vsup) is reached. The device has 1 outputs. In standby mode, the maximum current is 4μA.
74LVC2G02DP-Q100H Features
NOR Gate Logic Type
Operating Temperature: -40°C~125°C
LVC/LCX/Z Family
Quiescent Current: 10μA
74LVC2G02DP-Q100H Applications
There are a lot of Nexperia USA Inc.
74LVC2G02DP-Q100H Gates and Inverters applications.
