NX3225GA-20.000M-STD-CRG-2 Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
12 Weeks
Mount
Surface Mount
Mounting Type
Surface Mount
Package / Case
4-SMD, No Lead
Number of Pins
4
Operating Temperature
-40°C~85°C
Packaging
Tape & Reel (TR)
Series
NX3225GA
Size / Dimension
0.126Lx0.098W 3.20mmx2.50mm
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Type
MHz Crystal
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Frequency
20MHz
Frequency Stability
±30ppm
ESR (Equivalent Series Resistance)
50Ohms
Load Capacitance
8pF
Operating Mode
Fundamental
Frequency Tolerance
±20ppm
Height
889μm
Height Seated (Max)
0.035 0.90mm
Length
3.2004mm
Width
2.4892mm
RoHS Status
RoHS Compliant
In-Stock:10349 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
NX3225GA-20.000M-STD-CRG-2 Product Details
NDK Crystals NX3225GA-20.000M-STD-CRG-2 is a surface mount crystal oscillator with a frequency of 20.0000MHz and an 8pF load capacitance. It is a standard-sized crystal with a 2.0mm x 1.6mm footprint. This crystal is designed for use in a wide range of applications, including consumer electronics, automotive, medical, and industrial.
Features of the NDK Crystals NX3225GA-20.000M-STD-CRG-2 include a frequency stability of ±20ppm, a frequency tolerance of ±30ppm, and a temperature stability of ±20ppm. It also has a low power consumption of 1.2mA and a high shock resistance of up to 10,000g. The crystal is RoHS compliant and has a maximum operating temperature of +85°C.
The NDK Crystals NX3225GA-20.000M-STD-CRG-2 is suitable for a variety of applications, including clocks, timers, frequency synthesizers, and microprocessors. It is also suitable for use in radio frequency (RF) applications, such as wireless communication systems, GPS receivers, and satellite navigation systems.
