Name: MP174GS
Brand: Monolithic Power Systems Inc.
SKU: MP174GS
Availability: InStock

new-10%

MP174GS

Manufacturer part number:MP174GS

Manufacturer:Monolithic Power Systems Inc.

Description:8 Terminations5.3V~5.6V AC to DC power converter

Case Package:SOT-23

Datasheet:MP174GS Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width)
Surface Mount	YES
Operating Temperature	-40°C~125°C TJ
Packaging	Tube
Published	2008
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	8
ECCN Code	EAR99
Power (Watts)	5W
HTS Code	8542.39.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Number of Functions	1
Terminal Pitch	1.27mm
JESD-30 Code	R-PDSO-G8
Input Voltage-Nom	5.5V
Analog IC - Other Type	SWITCHING REGULATOR
Voltage - Supply (Vcc/Vdd)	5.3V~5.6V
Control Features	Soft Start
Input Voltage (Min)	5.3V
Topology	Boost, Buck, Buck-Boost, Flyback
Control Mode	VOLTAGE-MODE
Output Current-Max	0.72A
Input Voltage (Max)	5.6V
Internal Switch(s)	No
Fault Protection	Open Loop, Over Load, Over Temperature, Short Circuit
Output Isolation	Non-Isolated
Voltage - Breakdown	700V
Height Seated (Max)	1.75mm
Length	4.9mm
Width	3.9mm
RoHS Status	ROHS3 Compliant

MP174GS Product Details

MP174GS Overview

In the 8-SOIC (0.154, 3.90mm Width) package, the ac to dc converter is embedded.The ac dc converter is available in Tube case.There is a AC/DC converter mounted in the way of Surface Mount .It is recommended that the ac dc converter be operated at a temperature of -40°C~125°C TJ in order to ensure its performance.Analog IC type SWITCHING REGULATOR is utilized in this AC DC converter.Within the range of 5.3V~5.6V supply voltage (Vcc/Vdd), it can be used.There are a total of 8 terminations.Using a unique technique, it is possible to ensure an input voltage with a maximum value of 5.6V .An amount of current of 0.72A is the maximum that can be supplied to the ac to dc inverter.
