Name: SMAJ4468E3/TR13
Brand: Microsemi Corporation
SKU: SMAJ4468E3/TR13
Availability: InStock

new-10%

SMAJ4468E3/TR13

Manufacturer part number:SMAJ4468E3/TR13

Manufacturer:Microsemi Corporation

Description:8Ohms ±5% 13V 50nA @ 10.4V -55°C~150°C 1.5W DO-214AC, SMA

Case Package:SOT-23

Datasheet:SMAJ4468E3/TR13 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Number of Pins	2
Supplier Device Package	DO-214AC (SMAJ)
Operating Temperature	-55°C~150°C
Packaging	Tape & Reel (TR)
Published	1999
Tolerance	±5%
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Max Power Dissipation	1.5W
Impedance	8Ohm
Element Configuration	Single
Current - Reverse Leakage @ Vr	50nA @ 10.4V
Voltage - Forward (Vf) (Max) @ If	1.2V @ 200mA
Power - Max	1.5W
Max Reverse Leakage Current	50nA
Impedance-Max	8Ohms
Voltage - Zener (Nom) (Vz)	13V
Zener Voltage	13V
Radiation Hardening	No
RoHS Status	RoHS Compliant

SMAJ4468E3/TR13 Product Details

SMAJ4468E3/TR13 Overview

It is necessary to supply this electrical device with a reverse leakage current of 50nA @ 10.4V.Reverse leakage current reaches a maximum of 50nA.In operation, the maximum voltage - Zener (Nom) is set to 13V.For the device to operate, the maximum forward voltage (Vf) 1.2V @ 200mA must be supplied.
