Name: JAN1N4618UR-1
Brand: Microsemi Corporation
SKU: JAN1N4618UR-1
Price: 6.30000 USD
Availability: InStock

new-10%

JAN1N4618UR-1

Manufacturer part number:JAN1N4618UR-1

Manufacturer:Microsemi Corporation

Description:ZENER DIODE 1.5kOhm ±5% 2.7V 500nA @ 1V -65°C~175°C 2 Terminations DO-213AA (Glass)

Case Package:SOT-23

Datasheet:JAN1N4618UR-1 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	IN PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time	14 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	DO-213AA (Glass)
Number of Pins	2
Diode Element Material	SILICON
Operating Temperature	-65°C~175°C
Packaging	Bulk
Series	Military, MIL-PRF-19500/435
Published	1999
Tolerance	±5%
JESD-609 Code	e0
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Additional Feature	HIGH RELIABILTY
HTS Code	8541.10.00.50
Terminal Position	END
Terminal Form	WRAP AROUND
Pin Count	2
Reference Standard	MIL-19500
Qualification Status	Qualified
Number of Elements	1
Polarity	UNIDIRECTIONAL
Power Dissipation-Max	0.5W
Element Configuration	Single
Diode Type	ZENER DIODE
Current - Reverse Leakage @ Vr	500nA @ 1V
Voltage - Forward (Vf) (Max) @ If	1.1V @ 200mA
Case Connection	ISOLATED
Power - Max	500mW
Max Reverse Leakage Current	1μA
Impedance-Max	1.5kOhm
Reference Voltage	2.7V
Zener Voltage	2.7V
Voltage Tol-Max	5%
Dynamic Impedance-Max	1500Ohm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant

JAN1N4618UR-1 Product Details

JAN1N4618UR-1 Overview

It is necessary to supply this electrical device with a reverse leakage current of 500nA @ 1V.A voltage of 5% indicates the maximum voltage (Tol) that can be supplied.Reverse leakage current reaches a maximum of 1μA.For the device to operate, the maximum forward voltage (Vf) 1.1V @ 200mA must be supplied.
