Name: CDLL5532A
Brand: Microsemi Corporation
SKU: CDLL5532A
Price: 6.23000 USD
Availability: InStock

new-10%

CDLL5532A

Manufacturer part number:CDLL5532A

Manufacturer:Microsemi Corporation

Description:ZENER DIODE 90Ohm ±10% 12V 50nA @ 9.5V -65°C~175°C 500mW 2 Terminations DO-213AB, MELF

Case Package:SOT-23

Datasheet:CDLL5532A Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time	15 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	DO-213AB, MELF
Diode Element Material	SILICON
Operating Temperature	-65°C~175°C
Packaging	Bulk
Published	2013
Tolerance	±10%
JESD-609 Code	e0
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
HTS Code	8541.10.00.50
Max Power Dissipation	500mW
Terminal Position	END
Terminal Form	WRAP AROUND
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	not_compliant
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Pin Count	2
JESD-30 Code	O-LELF-R2
Qualification Status	Not Qualified
Number of Elements	1
Polarity	UNIDIRECTIONAL
Configuration	SINGLE
Impedance	90Ohm
Diode Type	ZENER DIODE
Current - Reverse Leakage @ Vr	50nA @ 9.5V
Voltage - Forward (Vf) (Max) @ If	1.1V @ 200mA
Impedance-Max	90Ohm
Reference Voltage	12V
Voltage - Zener (Nom) (Vz)	12V
Zener Voltage	12V
Voltage Tol-Max	10%
JEDEC-95 Code	DO-213AA
Working Test Current	1mA
RoHS Status	Non-RoHS Compliant

CDLL5532A Product Details

CDLL5532A Overview

An electrical device like this requires a reverse leakage current of 50nA @ 9.5V.A maximum voltage (Tol) can be supplied if 10% is set.While the device is operating, the maximum voltage - Zener (Nom) is reduced to 12V.This device must be operated with the working test voltage set to 1mA.For operation, diode reaches 1.1V @ 200mA at the maximum voltage - Forward (Vf).
