Name: SG7815AT
Brand: Microchip Technology
SKU: SG7815AT
Availability: InStock

new-10%

SG7815AT

Manufacturer part number:SG7815AT

Manufacturer:Microchip Technology

Description:Current Limit, Enable Fixed SG7815 PMIC Military, MIL-STD-883 Series 3 TO-205AD, TO-39-3 Metal Can

Case Package:SOT-23

Datasheet:SG7815AT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	IN PRODUCTION (Last Updated: 3 weeks ago)
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	TO-205AD, TO-39-3 Metal Can
Number of Pins	3
Supplier Device Package	TO-39
Mounting Style	SMD/SMT
Package	Bulk
Base Product Number	SG7815
Mfr	Microchip Technology
Product Status	Active
Maximum Operating Temperature	+ 150 C
Minimum Operating Temperature	- 55 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Operating Temperature	-55°C~125°C TA
Packaging	Bulk
Series	Military, MIL-STD-883
Published	1999
JESD-609 Code	e0
Pbfree Code	no
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	TIN LEAD
Terminal Position	BOTTOM
Terminal Form	WIRE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	SG7815
Pin Count	3
Current - Supply (Max)	7mA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	50V
Output Voltage	15V
Output Type	Fixed
Max Output Current	1.5A
Polarity	Positive
Output Configuration	Positive
Output Current	1.5 A
Current - Output	1.5A
Quiescent Current	6mA
Control Features	Current Limit, Enable
Accuracy	1.5 %
Output Voltage 1	15V
Voltage - Output (Min/Fixed)	15V
Number of Regulators	1
Protection Features	Over Current, Over Temperature
Voltage Dropout (Max)	2.5V @ 500mA
PSRR	60dB (120Hz)
Product Type	Linear Voltage Regulators
Dropout Voltage1-Nom	2V
Voltage - Output (Max)	-
Line Regulation	75 mV
Load Regulation	50 mV
Product	Fixed Voltage Regulators
Product Category	Linear Voltage Regulators
Radiation Hardening	Yes
RoHS Status	Non-RoHS Compliant
Lead Free	Exempt

SG7815AT Product Details

SG7815AT Overview

This Voltage Regulator IC comes inBulk packaging. This battery regulator is contained in a TO-205AD, TO-39-3 Metal Can package. There are 3 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Through Hole. The IC Regulator is set to operate at -55°C~125°C TA degrees. This regulator's output function is configured to be Positive. Its current output stands at 1.5A. IC voltage regulator has a sum of 3 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. The component's pin number remains 3. FYI, the basic part number for this IC regulator is SG7815. It works in 1.5A output current at mostIt operates in the 6mA Quiescent Current state. It is part of the Military, MIL-STD-883 Series.
