Name: PIC32MZ1024ECG100-I/PF
Brand: Microchip Technology
SKU: PIC32MZ1024ECG100-I/PF
Price: 15.93000 USD
Availability: InStock

new

PIC32MZ1024ECG100-I/PF

Manufacturer part number:PIC32MZ1024ECG100-I/PF

Manufacturer:Microchip Technology

Description:1MB 1M x 8 FLASH MIPS32® microAptiv™ 32-Bit Microcontroller PIC® 32MZ Series PIC32MZ1024ECG 100 Pin 200MHz 3.3V 100-TQFP

Case Package:SOT-23

Datasheet:PIC32MZ1024ECG100-I/PF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	100-TQFP
Surface Mount	YES
Number of Pins	100
Supplier Device Package	100-TQFP (14x14)
Weight	657.000198mg
Mounting Style	SMD/SMT
Interfaces	I2C/I2S/SPI/UART/USB
Number of I/Os	78 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	JTAG, I2C, PMP, SPI, SQI, UART, USB
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	MIPS32
RoHS	Details
Package	Tray
Base Product Number	PIC32MZ1024ECG100
Mfr	Microchip Technology
Data Converters	A/D 40x10b
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	PIC® 32MZ
Published	2011
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Frequency	200MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC32MZ1024ECG
Supply Voltage-Min (Vsup)	2.3V
Interface	EBI/EMI, Ethernet, I2C, I2S, SPI, UART, USART, USB
Memory Size	1MB
Oscillator Type	Internal
Number of I/O	78
Speed	200MHz
RAM Size	512K x 8
Voltage - Supply (Vcc/Vdd)	2.3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	MIPS32® microAptiv™
Peripherals	Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	1MB 1M x 8
Connectivity	EBI/EMI, Ethernet, I2C, SPI, SQI, UART/USART, USB OTG
Bit Size	32
Data Converter	A/D 40x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
Number of Timers/Counters	9
Product Type	32-bit Microcontrollers - MCU
Core Architecture	PIC
EEPROM Size	-
CPU Family	PIC
Number of ADC Channels	40
Number of I2C Channels	5
Number of SPI Channels	6
Number of Ethernet Channels	1
Product Category	32-bit Microcontrollers - MCU
Device Core	PIC
Height	1.05mm
Length	14mm
Width	14mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC32MZ1024ECG100-I/PF Product Details
