Name: PIC32MX564F128LT-I/PF
Brand: Microchip Technology
SKU: PIC32MX564F128LT-I/PF
Price: 6.90000 USD
Availability: InStock

new-10%

PIC32MX564F128LT-I/PF

Manufacturer part number:PIC32MX564F128LT-I/PF

Manufacturer:Microchip Technology

Description:128KB 128K x 8 FLASH MIPS32® M4K™ 32-Bit Microcontroller PIC® 32MX Series PIC32MX564F128L 100 Pin 80MHz 3.3V 100-TQFP

Case Package:SOT-23

Datasheet:PIC32MX564F128LT-I/PF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	24 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	100-TQFP
Number of Pins	100
Supplier Device Package	100-TQFP (14x14)
Mounting Style	SMD/SMT
Interfaces	CAN/I2C/SPI/UART/USB
Data Converters	A/D 16x10b
Number of I/Os	85 I/O
Maximum Operating Temperature	+ 85 C
Interface Type	I2C, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	MIPS32
RoHS	Details
Package	Tape & Reel (TR)
Base Product Number	PIC32MX564
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® 32MX
Published	2010
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Subcategory	Microcontrollers - MCU
Terminal Position	QUAD
Terminal Form	GULL WING
Supply Voltage	3.3V
Frequency	80MHz
Base Part Number	PIC32MX564F128L
Pin Count	100
Supply Voltage-Min (Vsup)	2.3V
Interface	CAN, I2C, SPI, UART, USART, USB
Max Supply Voltage	3.6 V
Min Supply Voltage	2.3 V
Memory Size	128kB
Oscillator Type	Internal
Number of I/O	85
Speed	80MHz
RAM Size	32K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	32
Core Processor	MIPS32® M4K™
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	128KB 128K x 8
Connectivity	CANbus, I2C, SPI, UART/USART, USB OTG
Bit Size	32
Data Converter	A/D 16x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
Number of Timers/Counters	5 Timer
Product Type	32-bit Microcontrollers - MCU
Core Architecture	PIC
EEPROM Size	--
Max Frequency	80 MHz
Number of A/D Converters	1
Number of Programmable I/O	85
Number of UART Channels	6
Number of ADC Channels	16
Number of PWM Channels	5
Number of I2C Channels	5
Number of SPI Channels	4
Number of USB Channels	1
Product	MCU
Product Category	32-bit Microcontrollers - MCU
Height	1.0414mm
Length	13.9954mm
Width	13.9954mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC32MX564F128LT-I/PF Product Details

PIC32MX564F128LT-I/PF Overview

A 100-TQFP package is included. In total, it has 85 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 32-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~85°C TA. PIC® 32MX series components belong to this electrical component. Its program memory size is 128KB 128K x 8. There is a MIPS32® M4K™ Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 100 terminations in total. The part works on a 32-bit basis. An output voltage of 3.3V volts is available for this Microcontroller chip. The Microcontroller chip has YES DMA channels. 128kB memory size belongs to the part. PIC32MX564F128L is the base part number that you can use to find alternatives. A good performance can be achieved at a frequency of 80MHz, as long as it is operated at a low power consumption. In order for the device to work with the motor, it utilizes the PWM channel YES. On the chip, there are 100 pins that are accessible. A total of 5 Timer timers/counters are included in the package. A total of 100 pins are present. There's built-in FLASH memory in the equipment. It is built on a PIC core architecture. This 8 Programmable I/O section allows you to program the device in many different ways depending on what you need. The device has 6 UART channels. In total, there are 16 channels for the ADC on this board. The Microcontroller has 1 A/D converters. 32 bits are found on a chip. A total of 5 PWM channels are used by the device. Devices like this use an 5-channel PWM controller.
