Name: PIC18LF46J50T-I/ML
Brand: Microchip Technology
SKU: PIC18LF46J50T-I/ML
Availability: InStock

new-10%

PIC18LF46J50T-I/ML

Manufacturer part number:PIC18LF46J50T-I/ML

Manufacturer:Microchip Technology

Description:64KB 32K x 16 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 18J Series PIC18LF46J50 44 Pin 48MHz 2.5V 44-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC18LF46J50T-I/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-VQFN Exposed Pad
Number of Pins	44
Supplier Device Package	44-QFN (8x8)
Interfaces	I2C/SPI/USART/USB
RoHS	Compliant
Package	Tape & Reel (TR)
Base Product Number	PIC18LF46
Mfr	Microchip Technology
Data Converters	A/D 13x10b
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® XLP™ 18J
Published	2011
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	44
ECCN Code	3A001.A.3
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES AT 8 MHZ AT 2 V
Max Power Dissipation	1W
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	2.5V
Frequency	48MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18LF46J50
Pin Count	44
Interface	I2C, SPI, UART, USART, USB
Max Supply Voltage	3.6 V
Min Supply Voltage	2 V
Memory Size	64kB
Oscillator Type	Internal
Number of I/O	34
Speed	48MHz
RAM Size	3.8K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	64KB 32K x 16
Connectivity	I2C, SPI, UART/USART, USB
Bit Size	8
Data Converter	A/D 13x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	5
ROM (words)	32768
Core Architecture	PIC
EEPROM Size	-
On Chip Program ROM Width	16
CPU Family	PIC
Max Frequency	31 kHz
Number of Programmable I/O	22
Device Core	PIC
Length	8mm
Height Seated (Max)	1mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC18LF46J50T-I/ML Product Details

PIC18LF46J50T-I/ML Overview

In a 44-VQFN Exposed Pad package, the MCU is available. 34 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 8-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~85°C TA that is operated by this Microcontroller. PIC® XLP™ 18J series components make up this electrical component. 64KB 32K x 16 is the size of its program memory. A PIC Core processor is used to power the device. This device falls under the MICROCONTROLLER uPs/uCs/Peripheral ICs category. 44 is the number of terminations on the IC chip that are present. This part works in a 8-bit manner. There is a 2.5V volt supply output on the chip. DMA channels number YES. 64kB is the memory size of the part. The base part number PIC18LF46J50 can be used to find alternatives. The efficiency of this device can be improved when operating at a frequency of 48MHz. The device works in YES PWM channels. Located on the chip are 44 pins. The clock has 5 timers or counters on it. There are 44 pins on it. In this device, there is a PIC CPU embedded within it. It has built-in FLASH memory. There is an integrated PIC core architecture in it. It programs in 22 Programmable I/O. I would like to mention a few additional features such as ALSO OPERATES AT 8 MHZ AT 2 V in order to name a few.
