Name: PIC18LC601T-I/L
Brand: Microchip Technology
SKU: PIC18LC601T-I/L
Availability: InStock

new-10%

PIC18LC601T-I/L

Manufacturer part number:PIC18LC601T-I/L

Manufacturer:Microchip Technology

Description:-- ROMless PIC 8-Bit Microcontroller PIC® 18C Series PIC18LC601 68 Pin 25MHz 5V 68-LCC (J-Lead)

Case Package:SOT-23

Datasheet:PIC18LC601T-I/L Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	68-LCC (J-Lead)
Surface Mount	YES
Number of Pins	68
Supplier Device Package	68-PLCC (24.23x24.23)
Data Converters	A/D 8x10b
Number of I/Os	47
RoHS	Compliant
Package	Tape & Reel (TR)
Base Product Number	PIC18LC601
Mfr	Microchip Technology
Product Status	Obsolete
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® 18C
Published	2005
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	68
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES AT 2 V MINIMUM SUPPLY
Max Power Dissipation	1W
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	245
Supply Voltage	5V
Terminal Pitch	1.27mm
Frequency	25MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18LC601
Pin Count	68
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	2.5/5V
Supply Voltage-Min (Vsup)	2V
Interface	EBI/EMI, I2C, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	4.2 V
Oscillator Type	External
Number of I/O	26
Speed	25MHz
RAM Size	1.5K x 8
Memory Type	ROMless
Voltage - Supply (Vcc/Vdd)	2V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, LVD, POR, PWM, WDT
Program Memory Type	ROMless
Core Size	8-Bit
Program Memory Size	--
Connectivity	EBI/EMI, I2C, SPI, UART/USART
Supply Current-Max	50mA
Bit Size	8
Data Converter	A/D 8x10b
Access Time	25 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	4
Address Bus Width	16
ROM (words)	0
Core Architecture	PIC
EEPROM Size	--
CPU Family	PIC
Max Frequency	25 MHz
Number of Programmable I/O	47
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC18LC601T-I/L Product Details

PIC18LC601T-I/L Overview
