Name: PIC18F97J60T-I/PT
Brand: Microchip Technology
SKU: PIC18F97J60T-I/PT
Price: 8.64000 USD
Availability: InStock

new

PIC18F97J60T-I/PT

Manufacturer part number:PIC18F97J60T-I/PT

Manufacturer:Microchip Technology

Description:128KB 64K x 16 FLASH PIC 8-Bit Microcontroller PIC® 18J Series PIC18F97J60 100 Pin 41.667MHz 3V 100-TQFP

Case Package:SOT-23

Datasheet:PIC18F97J60T-I/PT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	100-TQFP
Number of Pins	100
Supplier Device Package	100-TQFP (12x12)
Mounting Style	SMD/SMT
Interfaces	Ethernet/I2C/SPI/USA
Data Converters	A/D 16x10b
MSL	MSL 1 - Unlimited
Qualification	-
Number of I/Os	70 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	Display Driver, EUSART, Ethernet, I2C, MSSP, SPI
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	PIC
RoHS	Details
Schedule B	8542310000, 8542310000/8542310000, 8542310000/8542310000/8542310000, 8542310000/8542310000/8542310000/8542310000
Product Status	Active
Mfr	Microchip Technology
Base Product Number	PIC18F97
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® 18J
Published	2006
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Termination	SMD/SMT
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES AT 2V MINIMUM SUPPLY AT 4 MHZ
Max Power Dissipation	1W
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.4mm
Frequency	41.667MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18F97J60
Pin Count	100
Operating Supply Voltage	3.6V
Interface	EBI/EMI, Ethernet, I2C, SPI, UART, USART
Max Supply Voltage	3.9 V
Min Supply Voltage	2 V
Memory Size	128kB
Oscillator Type	Internal
Number of I/O	70
Speed	41.6667 MHz
RAM Size	3808 x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	128KB 64K x 16
Connectivity	EBI/EMI, Ethernet, I2C, SPI, UART/USART
Supply Current-Max	21.6mA
Bit Size	16
Data Converter	A/D 16x10b
Watchdog Timer	Yes
Access Time	42 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
Number of Timers/Counters	5
Address Bus Width	20
Product Type	8-bit Microcontrollers - MCU
Density	1 Mb
ROM (words)	131072
Core Architecture	PIC
EEPROM Size	--
CPU Family	PIC
Max Frequency	41.667 MHz
Number of Programmable I/O	70
Number of ADC Channels	16
Number of PWM Channels	14
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Length	12mm
Height Seated (Max)	1.2mm
Width	12 mm
Height	1 mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC18F97J60T-I/PT Product Details
