Name: PIC16LF1947-E/MR
Brand: Microchip Technology
SKU: PIC16LF1947-E/MR
Availability: InStock

new-10%

PIC16LF1947-E/MR

Manufacturer part number:PIC16LF1947-E/MR

Manufacturer:Microchip Technology

Description:28KB 16K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16LF1947 64 Pin 32MHz 3.3V 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC16LF1947-E/MR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	64-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	64
Supplier Device Package	64-QFN (9x9)
Interfaces	I2C/SPI/USART
Package	Tube
Base Product Number	PIC16LF1947
Mfr	Microchip Technology
Data Converters	A/D 17x10b
Product Status	Active
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	PIC® XLP™ 16F
Published	2008
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Finish	Matte Tin (Sn)
Max Power Dissipation	800mW
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Frequency	32MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC16LF1947
Pin Count	64
Supply Voltage-Max (Vsup)	3.6V
Interface	I2C, LIN, SPI, UART, USART
Memory Size	28kB
Oscillator Type	Internal
Number of I/O	54
Speed	32MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	8
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, LCD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	28KB 16K x 14
Connectivity	I2C, LINbus, SPI, UART/USART
Bit Size	16
Data Converter	A/D 17x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
DAC Channels	NO
EEPROM Size	256 x 8
CPU Family	PIC
Number of A/D Converters	1
Number of UART Channels	2
Number of PWM Channels	5
Device Core	PIC
Height	950μm
Length	9mm
Width	9mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC16LF1947-E/MR Product Details

PIC16LF1947-E/MR Overview

In a 64-VFQFN Exposed Pad package, the MCU is available. 54 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 8-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~125°C TA that is operated by this Microcontroller. PIC® XLP™ 16F series components make up this electrical component. 28KB 16K x 14 is the size of its program memory. A PIC Core processor is used to power the device. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 64 is the number of terminations on the IC chip that are present. This part works in a 16-bit manner. There is a 3.3V volt supply output on the chip. DMA channels number NO. 28kB is the memory size of the part. The base part number PIC16LF1947 can be used to find alternatives. The efficiency of this device can be improved when operating at a frequency of 32MHz. Located on the chip are 64 pins. There are 64 pins on it. In this device, there is a PIC CPU embedded within it. 2 UART channels are available on it. The MCU has 1 A/D converters. This Microcontroller is possible to have 8 bits in a chip. The device uses 5 PWM channels.
